Supports 4G or WiFi
Ultra low bandwidth traffic cost
Can be connected to multiple access control readers externally
Compact size and portable installation
1) 4G WiFi 、 Bluetooth wireless access
2) Supports standard single door controller functions, with one Wiegand input, one relay output, and one door magnetic input
3) Support traditional reader access such as card swiping and password authentication
4) Innovative visitor temporary password, remote door opening, Bluetooth door opening and other Internet single door access methods
5) Support professional access control time management, with a compact size and powerful functions.
6) Compact in size, suitable for embedded installation, suitable for use in countries such as North America, Europe, South America, the Middle East, Africa, and Southeast Asia
7) Stable transmission, strong reliability, and high cost-effectiveness
8) Support secondary development and provide development packages
| Open Mode | Swipe card (IC card)to open the door, Bluetooth to openthe door, remote to open the door, exit switch to open the door, etc |
| Communication Method |
Bluetooth standard, optional 4G/NBito/WiFi |
| Master Chip | DA14585 |
| Memory | 768KB |
| Storage | 8M |
| RFCard Type | Supports card readingheads inputthrough the Weigend interface, with the support type determinedbythereading head |
| Networking Method | Choose between Bluetooth or WiFi/4G |
| Card Capacity | 8000 |
| Bluetooth Door Opening Distance |
Within 10 meters without obstruction |
| Power Supply | 12V DC/2A(Equipment control lock requires additional electriclock current) |
BC240 4G WiFi Mini is a new generation of single door access controller based on Internet and Internet of Things technology, which supports 4G or WiFi access,The network can be configured through Bluetooth on the mobile phone, and various traditional access control readers can be
connected externally. It is simple and easy to use, supports offline and online use, and is safe
and convenient,It is the preferred single door access control product for small and medium-sized scenarios. Built in network automatic diagnostic technology, which will automatically attempt to repair the connected network in case of network disconnection in special circumstances.
The built-in Bluetooth function supports the mobile door opening function when the network is disconnected, and meets the user's mobile door opening function through remote door opening and near-field Bluetooth door opening,No need to bring a card. For the first time in the industry, such a small-sized device has implemented built-in access control time period function,
supporting professional access control time period management and powerful functionality.
